The Barrel Bridge
Reference no 105
In the figure above all the Bridges and Cocks are put into their positions at the Main Plate.
|
|
The Barrel Bridge Reference no 105
|
|
|
|
|
The Barrel Bridge (105) holds the barrel in
place and is screwed into the Main Plate (100).
|
|
|
|
|
|
In the figure above the Main Plate can be
seen in the center. To the upper right is the Pallet Lever Cock and to
the lower right is the Balance Cock. The Barrel Bridge can be seen up
left and down right is the Wheel Train Bridge.
|
|
|
|
|
|
In the figure above all the Bridges and Cocks are put into their positions at the Main Plate. |
|
|
|
|
